Molnar Technologies Rods and Cranks
Psst. don't forget your MOLNAR Crank		   Molnar Technologies Connecting Rods
 Audi/BMW/Chevy/Ford/GM/Honda/Hyundai/Mazda/
Mitsubishi/Nissan/Opel/Subaru/Suzuki/Toyota/VW

H-Beam Billet Connecting Rods
Our H-Beam Connecting Rods are made from 4340 billet material, heat treated to increase tensile strength and are shot peened to increase fatigue life. All rods have a wear resistant bronze bushing for long wrist pin life and feature ARP fasteners. All Molnar Technologies connecting rods are finished here in the US at our factory near Grand Rapids Michigan. Sizes are held +/- .0001" which is the tightest tolerances you will find in the racing industry.

All Rods Include 3/8 ARP2000 Bolts!
NOTE: All Rods have STOCK Rod Pin size.

CUSTOM Rods for Your Engine!
We offer Custom Designed H-Beam Rods for most Sport Compact engines. Email us for a price quote for your engine right now!

ORDER Molnar Rods
Email: Sales@Flatlander-IPP.nl
Ph: 0031 (0) 545-291505 (Office)
Ph: + 31 (0)6-23360358 (cell)
FAX: 0031-545295648
Part # Description C-C WEight Bolt BE
Bore		 Pin
Size		 BE
Width		 PE
Width		 Price
For All Other Applications NOT Listed Below
CUSTOM Rods available, please call or email us for pricing (make sure to have your engine specs)
AUDI/VW
VWH5669AFEB4-A1.8L Golf 5.669536 3/8 ARP20001.992 20mm0.982 0.982 €499
VWH5669AFETB4 5.669 VW TFSI w/ Tapered Pin End 5.669 547 3/8 ARP2000 1.992 21mm 0.982 0.982 €499

BMW
BMWH5315CFB6-AM52 B32 / M54 B30 5.315484 3/8 ARP20001.890 22mm0.862 0.862 €699
BMWH5472KEB6-AS54 B32 5.472496 3/8 ARP20002.087 21mm0.784 0.784 €699

CHEVY/GM
CH5709AWJB4-AECOTEC 2.0 LNF 5.709549 3/8 ARP20002.052 23mm0.945 0.945 €499
CH5728AWJB4-AECOTEC 2.0 LSJ 5.728545 3/8 ARP20002.052 23mm0.945 0.945 €499
CH5590LADB4-ALN2 5.590499 3/8 ARP20002.125 0.8001.034 0.900 €499
CH5659AWCB4-AECOTEC 2.4 LE5 5.659532 3/8 ARP20002.052 20mm0.945 0.945 €499
CH6000WNB6-ALFX V6 6.000609 3/8 ARP20002.374 24mm0.856 0.856 €699
CH6004JNB4-AECOTEC 2.0 LTG 6.004581 3/8 ARP20002.052 24mm1.042 1.042 €499

FORD
FH5758DEB4-A1.8L / 2.0L Duratec 5.758515 3/8 ARP20001.970 21mm0.860 0.710 €499
FH6094KEB4-A2.3L Duratec - Not Speed 3 6.094538 3/8 ARP20002.088 21mm0.859 0.860 €499
FH6136MGB4-A2.0L EcoBoost 6.136571 3/8 ARP20002.166 22.5000.858 0.858 €499

HONDA / ACURA
HH5287CEB4-AB16 5.287472 3/8 ARP20001.890 21mm0.937 0.790 €499
HH5393CBB4-AD16 5.394488 3/8 ARP20001.890 19mm0.895 0.921 €499
HH5394CBB4-AD17 5.394460 3/8 ARP20001.890 19mm0.780 0.846 €499
HH5394CEB4-AB18A/B 5.394485 3/8 ARP20001.890 21mm0.937 0.790 €499
HH5433CEB4-AB18C 5.433495 3/8 ARP20001.890 21mm0.857 0.857 €499
HH5472FFB4-AK20A Turbo 5.472502 3/8 ARP20002.008 22mm0.782 0.782 €499
HH5472FFB-L4-AK20A Lightweight 5.472450 3/8 ARP20002.008 22mm0.782 0.782 €499
HH5580FFB4F22 / B20A5 / H23 5.580541 3/8 ARP20002.008 22mm0.934 0.934 €499
HH5866AAB4-AFit / Jazz 5.866364 3/8 ARP20001.393 18mm0.702 0.702 €499
HH5984FFB4-AK24 Turbo 5.984535 3/8 ARP20002.008 22mm0.782 0.782 €499
HH5984FFB-L4K24 N/A Lightweight 5.984451 3/8 ARP20002.008 22mm0.782 0.782 €499
HH6200CCB4-AR18A 6.200460 3/8 ARP20001.890 20mm0.762 0.762 €499

HYUNDAI
HYH5146BBB4-A1.6L Veloster 5.146440 3/8 ARP20001.772 20mm0.742 0.742 €499
HYH5748FFB4-A2.0L Genesis 4B11 5.748523 3/8 ARP20002.008 22mm0.860 0.860 €499

MAZDA
ZH5234CCB4-AMX5 / B6 / BP 5.234482 3/8 ARP20001.890 20mm0.860 0.860 €499
ZH5315FBB4-A2.0L Protégé 5.315497 3/8 ARP20002.008 19mm0.858 0.860 €499
ZH5927MGB4-A2.3L DISI w/ Stock Size 22.5mm Pin 5.927558 3/8 ARP20002.167 22.5mm0.858 0.858 €499
ZH5976MCB4-AMZR 2.5L 5.976552 3/8 ARP20002.167 20mm0.859 0.708 €499
FH6094KEB4-A2.3L Duratec - Not Speed 3 6.094538 3/8 ARP20002.088 21mm0.859 0.860 €499

MITSUBISHI
MH5250CBB4-A4G93 5.250475 3/8 ARP20001.890 19mm0.860 0.860 €499
MH5659MJB4-A4B11 EVO X 5.659558 3/8 ARP20002.165 23mm0.861 0.784 €499
MH5906CFB4-A4G63 Gen 2 5.906539 3/8 ARP20001.890 22mm1.038 0.900 €499

NISSAN
NISSAN
NH4783FEB6-ARB25 / 26 4.783496 3/8 ARP20002.008 21mm0.857 0.857 €699
NH5364FFB4-ASR20 5.364517 3/8 ARP20002.008 22mm0.894 0.894 €499
NH5630CCB4-AQR25DE 5.630514 3/8 ARP20001.890 20mm0.896 0.900 €499

OPEL
OPH5106ABBB4-AZ16XE 5.106425 3/8 ARP20001.811 19mm0.860 0.700 €499
OPH5110ABAB4-AOpel X16 XE 5.110425 3/8 ARP20001.811 18mm0.862 0.712 €499
OPH5634JEB4-AC20XE 5.634529 3/8 ARP20002.047 21mm1.038 0.866 €499

ROTAX
RTH4724CJB3-ARotax 1503 4 Tec 4.724460 3/8 ARP20001.890 23mm0.865 0.865 €399

SUBARU
SH5137MJB4-AEJ20 / EJ25 5.138536 3/8 ARP20002.165 23mm0.842 0.842 €499
SH5180MJB4-AEJ25 Non Turbo 5.180538 3/8 ARP20002.165 23mm0.842 0.842 €499

SUZUKI
SUZUKI
SZH5354BCB4-AM18 5.354446 3/8 ARP20001.772 20mm0.936 0.740 €499
SZH5492ACBB4-AG16 A/B/D 5.492485 3/8 ARP20001.851 19mm0.866 0.866 €499

TOYOTA
TH4803ACB4-A4A-GEC 1985-1987 4.803421 3/8 ARP20001.693 20mm0.859 0.859 €499
TH4803BCB4-A4A-GE 1988-1991 4.803408 3/8 ARP20001.772 20mm0.858 0.858 €499
TH4843FFB4-A3TC 4.843522 3/8 ARP20002.008 22mm1.054 1.054 €499
TH5218FCB4-A7A-FE 5.218493 3/8 ARP20002.008 20mm0.858 0.858 €499
TH5315AJNB4-A2RZ-FE 2.4L 5.315621 3/8 ARP20002.205 24mm1.015 1.015 €499
TH5551AAB4-A1NZFE 5.551422 3/8 ARP20001.693 18mm0.704 0.704 €499
TH5590MFB6-A2JZ-GTE (all 2JZ models) 5.590578 3/8 ARP20002.167 22mm1.020 1.000 €699
TH5772ACCB4-A1ZZ 5.772465 3/8 ARP20001.850 20mm0.779 0.787 €499
TH5886FFB4-A2AZ-FE 5.886510 3/8 ARP20002.008 22mm0.780 0.780 €499
TH6200AWFB4-A2AR FE 6.200590 3/8 ARP20002.147 22mm0.858 0.858 €499
TH6300VFB6-A1GR-FE 6.300596 3/8 ARP20002.323 22mm0.818 0.818 €699

VW
VWH5669AFEB4-A1.8L Golf 5.669536 3/8 ARP20001.992 20mm0.982 0.982 €499
VWH5669AFETB45.669 VW TFSI w/ Tapered Pin End 5.669547 3/8 ARP20001.992 21mm0.982 0.982 €499

YAMAHA
YH5710BFB4-AWaverunner SHO 5.710511 3/8 ARP20001.772 22mm1.056 0.824 €525
